Designed Especially For Framing Nailers
- Oil lubricated for cooler operation and reduced noise
- High output cast iron pump delivers maximum performance and operational life
- Big BoreTM cylinder and piston feature high output at lower RPM with reduced heat buildup, less noise and longer operational life
- Low amperage draw reduces incidents of tripped breakers and voltage drops that cause premature motor failure
- Easy view oil gauge and large pressure gauges for quick identification
- Air pressure regulator enables easy adjustment of line pressure
- Features 2 quick connect air hose fittings
- Finned discharge tube promotes safe and efficient cooling
- Stores 50' of 3/8" air hose with handle folded or upright
INCLUDES: 1/4” Quick Coupler, (10TT-8), Compressor Oil (0.25L) (181122-A)
SPECIFICATIONS:
|
Motor |
3.0 hp |
|
Pump |
Oil-Lubricated |
|
Tank |
5.2 gal (19.7L) |
|
Performance (90 PSI) |
6.5 CFM |
|
Noise level |
90 dB(A) |
|
AMPS (120V) |
13.8 A |
|
Dimensions (L x W x H, with Handle Folded) |
30-5/16" x 20 x 21-13/16" (770 mm x 510 mm x 553 mm) |
|
Maximum Pressure |
140 PSI |
|
Net Weight |
88.0 lbs (39.9 kg) |
