FEATURES
- DURABLE THREADED DRIVER BLADE
Unlike competitors, MAX finish nailers have a driver blade that threads-in. This unique feature makes the tool last 4 times longer than pin style driver blades. - DUAL TRIGGER MODE
Switchable fire mechanism means the tool can move between contact fire and single fire mode with a simple switch of a lever. - PROTECT YOUR FACE FROM EXHAUST
Easy 360 degree twist adjustable exhaust deflector allows the user to easily divert exhaust air away from them self without any tool. - LIGHTWEIGHT AND COMPACT
Most powerful in its class at only 3.9 lbs. the slim body easily reaches into tight spaces. - CONSISTENTLY AND ACCURATELY SHOOTS NAILS
The depth adjustment dial allows operators to effortlessly drive nails into hard materials, and also control depth of drive when fastening soft materials, for a consistently polished finish. - EASILY CLEAR JAMS
Designed with an open nose to allow for easy jam clearance should any issues arise.
SPECIFICATIONS
|
WEIGHT
|
3.5 lbs
|
|---|---|
|
DIMENSIONS
|
11 3/16"(H) x 3 3/4"(W) x 11 11/16"(L) |
|
MINIMUM OPERATION PRESSURE
|
70 PSI
|
|
MAXIMUM OPERATION PRESSURE
|
120 PSI
|
|
AIR INLET SIZE
|
1/4"
|
|
MAGAZINE CAPACITY
|
100
|
|
DEPTH CONTROL
|
Yes
|
|
JAM CLEARING
|
Yes
|
|
TRIGGER TYPE |
Switchable Fire Trigger |
|
AIR CONSUMPTION
(FT3/CYCLE) |
0.032
|
|
ACCESSORIES
|
Allen key, Carry case
|
FASTENERS
|
COLLATION TYPE
|
Glue
|
|---|---|
|
NAIL GUN ANGLE
|
Straight |
|
STRIP OR COIL
|
Strip
|
|
COMPATIBLE FASTENER TYPES
|
Straight finish nails
|
|
MINIMUM FASTENER SIZE
|
1-1/4"
|
|
MAXIMUM FASTENER SIZE
|
2-1/2"
|
Applications
- Finish & trim
- Door/ window casing
- Cabinets
- Panel assembly
- Exterior trim
- Subflooring
